YTL-20C technical parameter

1. Rated pressure: 200kn, measurement error: ± 0.05% (F.S);

2. Test displacement: (0 ~ 25) mm, measurement error: ± 0.5% (F.S);

3. Loading rate: 0.5mm/min-50mm/min (freely settable);

4. Man machine interface: 7 Inch Touch color screen;

5. Working power supply: AC (220 ± 10%) V 50Hz;

6. Overall power consumption: 2500W;

7. Spacing between two columns: 320mm;

8. Overall dimension: 550 * 580 * 1400mm;
