1.Input air pressure: 0.5MPa

2.Output pressure: 10kN

3.Pressurizing stroke: 100mm

4.Instrument operation: 5-inch touch screen operation and control

5.Maximum applied pressure: 1T

6.Pressure display accuracy: 1N

7.Pressure detection: pressure sensor automatic detection

8.Pressure adjustment: precision pressure regulator, barometer display

9.Instrument protection: with oil-water separator, automatic protection of the ballast system

10.Ambient temperature: -10℃~ +35°C

11.Relative humidity:<85%.

12.Power supply:AC(220±10%)V 50Hz

13.Dimension:45x30x73cm

14.Weight:50kg
